LRC2208U2BC
- Home
- Products
- Enterprise Product - Server
- LRC2208U2BC
LRC2208U2BC
Model No: LRC2208U2BC
- System 2U Rackmount
- Front Panel (1) PWR / (1) ID / (1) Drive / (1) System Event
- Processor Xeon® 6 Processor
- Memory Up to 8192GB RDIMM
- Expansion Slots (8) 2.5″ Hot-Swap SSDs
The Latios LRC2208U2BC is an exceptional choice for enterprises and data centers seeking a next-generation server platform with unmatched performance, scalability, and reliability. Here’s why this server stands out:
Key Features
The Latios LRC2208U2BC is an ideal solution for industries requiring high-performance computing and scalability. Key applications include:
System
2U Rackmount
Front Panel
(1) PWR w/ LED / (1) ID w/ LED / (1) RST / (1) NMI
Processor
Xeon® 6 Processor
Memory
Up to 8192GB RDIMM
Expansion Slots
(8) 2.5″ Hot-Swap SSDs
Cooling System
Fan Cooler
Why Choose Latios Server LRC2208U2BC
The Latios Server LRC2208U2BC is an exceptional choice for enterprises and data centers seeking a next-generation server platform with unmatched performance, scalability, and reliability. Here’s why this server stands out:
Next-Generation Technology:
Succeeding the proven LRC2208U2BC platform, the LRC2208U2BC incorporates the latest innovations in compute, memory, and storage technologies, ensuring superior performance for demanding workloads.
Unrivaled Compute Power:
Supports Intel® Xeon® 6 Processors with TDP up to 350W, delivering industry-leading computational performance for data-intensive applications.
Multiple speakers recognition
As your business evolves, your technology should too. Latios offers modular hardware, remote management tools, and reliable support plans that grow with your team.
Future-Proof Memory Support:
Offers DDR5 memory support up to 8,192GB with speeds of 6400MT/s, ensuring your workloads benefit from the highest memory bandwidth and capacity.
Smarter, faster, AI-powered
By choosing the Latios Server LRC2208U2BC, organizations can enhance their infrastructure with a platform that combines cutting-edge technology, robust expandability, and industry-leading energy efficiency. This server is not just an investment in performance but also a future-proof solution for evolving enterprise and data center needs.
Flexible Expandability
Comprehensive PCIe 5.0 options and OCP v3.0 slots allow seamless integration of high-performance GPUs, storage controllers, and high-speed networking modules.
Space-Saving Design
Compact 2U chassis optimized for rack deployment, balancing high performance and space efficiency.
High-Performance Computing (HPC)
Supports intensive simulations, research applications, and engineering workloads, financial modeling, and data analysis.
Artificial Intelligence (AI) and Machine Learning (ML)
Offers robust processing and memory capabilities for AI model training and inference.
Virtualization and Cloud Computing
Enabling GPU-accelerated services in cloud environments.
Edge and Content Delivery Networks (CDNs)
Meets the low-latency and high-bandwidth needs of edge computing and content distribution.
Virtual Desktop Infrastructure (VDI)
Delivering reliable high-performance virtual desktops, ensuring smooth and efficient operations for graphic-intensive applications and end-user environments.
Tech Specification
| Category | Specification | Details |
|---|---|---|
| System | Form Factor | 2U Rackmount |
| Chassis Model | TX77 | |
| Dimension (D x W x H) | 30.31″ x 17.24″ x 3.43″ (770 x 438 x 87mm) | |
| Motherboard Name | 2208M | |
| Motherboard Notification | The motherboard not sold separately | |
| Gross Weight | 34.5 kg (76.06 lbs) | |
| Net Weight | 26.25 kg (57.87 lbs) | |
| Front Panel | Buttons | (1) PWR w/ LED / (1) ID w/ LED / (1) RST / (1) NMI |
| LEDs | (1) PWR / (1) ID / (1) Drive / (1) System Event | |
| I/O Ports | (1) USB 2.0 port / (1) USB 3.0 port | |
| Processor | Q’ty / Socket Type | (2) LGA4710 |
| Supported CPU Series | Xeon® 6 Processor | |
| Thermal Design Power | Max up to 350W (TDP) | |
| Memory | Supported DIMM Qty | (16)+(16) DIMM slots |
| Type / Speed | RDIMM / DDR5 6400 MT/s (1DPC) / 5200 MT/s (2DPC) / MRDIMM 8000 (1DPC) | |
| Capacity | Up to 8192GB RDIMM | |
| Memory Channel | 8-Channel DDR5 RDIMM / MRDIMM | |
| Memory Voltage | 1.1V | |
| Expansion Slots | PCIe | (1) PCIe Gen 5 x16 / (2) PCIe Gen 5 x16 (FH/HL) / (2) PCIe Gen 5 x16 (FH/FL) |
| Others | (2) PCIe Gen 5 x16 OCP 3.0 mezzanine slots | |
| External Drive Bay | Q’ty / Type | (8) 2.5″ Hot-Swap SSDs |
| Front Drive Bay Interface | (8) SATA 6Gb/s / SAS 24Gb/s / NVMe U.2 | |
| Backplane Support | SAS 24Gb/s / SATA 6Gb/s / NVMe | |
| Notification | Backplane connected via onboard PCIe MCIO | |
| Power Supply | Type | RPSU |
| Input Range | AC 100-127V/12A / AC 200-240V/8.5A | |
| Frequency | 50/60 Hz | |
| Output Watts | 2700W | |
| Efficiency | 80 Plus Titanium | |
| Cooling | Fan | (6) 6056 fans |
| LAN | Port | (1) GbE dedicated for IPMI |
| PHY | Realtek RTL8211F | |
| Storage NVMe | M.2 | (2) 22110/2280 via PCIe Gen 4 |
| U.2 | (4) SFF-TA-1016 (MCIO 8x) for (8) front NVMe | |
| Graphics | Connector Type | Mini DisplayPort |
| Resolution | Up to 1920×1200 | |
| Chipset | Aspeed AST2600 | |
| I/O Ports | USB | (1) USB 3.0 / (1) USB UART |
| DisplayPort | (1) Mini DisplayPort | |
| RJ-45 | (1) GbE for IPMI | |
| TPM (Optional) | TPM Support | TM-TPM2-MS-I-9672 |
| Interface | SPI | |
| System Monitoring | Chipset | Aspeed AST2600 |
| Temperature | Monitors CPU, memory, environment | |
| Voltage | Monitors CPU, memory, chipset & PSU | |
| LED | Over-temperature / Fan & PSU fail indicators | |
| Server Management | Onboard Chipset | Aspeed AST2600 (DCSCM) |
| iKVM Feature | 24-bit video, Storage over IP, Remote flash | |
| IPMI Feature | IPMI 2.0, 10/100/1000 Mb/s | |
| BIOS | Brand / ROM Size | AMI / 64MB |
| Features | PXE, SMBIOS 3.6, UEFI Secure Boot, Redfish, HTTP Boot | |
| Operating Environment | Operating Temp | 10°C ~ 35°C |
| Non-operating Temp | -40°C ~ 70°C | |
| Humidity | 85% Operating / 90% Non-operating | |
| Regulation | BIS | R-72014435 |
| CE (DoC) | NA | |
| CB/LVD | Yes | |
| RCM | Yes | |
| VCCI | Yes | |
| BSMI | Yes | |
| NRTL | Yes | |
| OS | OS Supported List | Refer to AVL lists |
| RoHS | RoHS 6/6 | Yes |
| RoHS 2.0 | Yes | |
| Package Contains | Barebone | (1) LRS-2208 Barebone |
| Manual | Quick Installation Guide | |
| Others | (2) E2A Carrier / (2) E2B Carrier | |
| Brochure | Download PDF |
